ELECTRIC MINIBUS

ELECTRIFIED SMALL CITY BUS

Designed to feed the main lines of city transportation, e-JEST can maneuver in narrow streets easily thanks to its compact size. Therefore, it allows a transportation network that can expand and access every point in the city.

Total Length (m)

5.8

Maximum Range (km)

210

Maximum Passenger Capacity

CONTACT ME BROCHURE GET A QUOTE

UNIQUE AND INNOVATIVE DESIGN

e-JEST respects and sustains the historical heritage of the city. Having a perfect look with its new age compact design, e-JEST is adapting to the texture of the city thanks to its small footprint. It increases the image of the city and becomes an iconic figure.

QUICK & EASY CHARGING

e-JEST easily charges itself through the charging socket at the rear right side. e-JEST, which can be charged with two types of AC and DC, recharges battery for 4 hours*at night and 65 minutes* with quick charging during the day.

MAXIMUM CAPACITY UTILIZATION

e-JEST reduces operational costs during off peak hours where oversized empty buses has redundant capacity. Thus, it offers the capacity as required by a city for these hours and brings an affordable approach to public transportation.

4 WHEEL INDEPENDENT SUSPENSION

Until e-JEST, passenger and driver comfort has not been expected in public transport. With 4-wheel independent suspension, e-JEST reduces road vibration and increases passenger comfort offering an automobile like comfort.

NEWS FROM KARSAN

All News

29 Aug

THREE STEVIE AWARDS FOR KARSAN

19 Aug

KARSAN LAUNCHES AUTONOMOUS E-ATAK FOR...

12 Jul

KARSAN WINS FOUR AWARDS FROM BRANDS R...

Other Models

FAQ

How much does it cost to buy an electric minibus?

Please contact us to get a quote.

How many seats does Karsan e-Jest minibus have?

e-Jest offers up to 10 fixed and 2 foldable seats.

How long does it take to charge e-Jest minibus?

With a 50 kW capacity quick charger e-Jest can be charged as quick as 55 minutes depending on battery variations and up to 80% state of charge.

What is maximum range of an electric minibus in kilometers?

With 88 kWh battery packs e-Jest offers 210 km range according to NEDC test cycle.

e-JEST - DESIGN

UNIQUE & INNOVATIVE DESIGN
AWARD WINNING STYLE

The exterior and interior design of e-JEST is formed as a small city bus by taking into account all needs for drivers and passengers of public transportation.

CONTACT ME BROCHURE GET A QUOTE

EXTERIOR DESIGN

Cataphoresis Coating

e-JEST chassis provides advanced corrosion resistance while preventing rust formation with its Cataphoresis Coating

Sliding Door

Wide door alternatives for your preference

Original Low Floor

Manual Ramp

Prompt & easy access with wheelchair access ramp availability

Attractive Front Design

Distinctive front design is a signature of e-Jest

LED Lighting Group

Impressive look with LED Headlights, Turn Signals, Fog and Daytime Running Lamps.

INTERIOR DESIGN

Front Looking Passenger Seats

Comfortable journeys with front looking passenger seats

Wheelchair Traveling Area

Freedom of travel for all residents

Passenger & Driver Air Conditioners

e-JEST offers both driver & passenger A/C as standard

LED Light Path for Passenger Area

Enhanced aesthetics & illumination with LED light path

USB Plugs On Hand Rails

Mobile devices will never run out of battery

10’’ Full Digital Cluster

IT provides all vehicle information and warnings for safe and easy operation.

10.1” Multimedia Touchscreen

Everything is at the tip of your fingers thanks to the e-JEST’s wide touchscreen

Relatively Higher Driver Compartment and Ergonomic Dashboard

Better feeling of safety & confidence and no more fatigue with ergonomic dashboard

Tiltable & Telescopic Hydraulic Steering Wheel

For a pleasant & relaxing journey

88 kWh DOUBLE BATTERY

e-JEST - SPECS

Vehicle Type

Powertrain System

Performance & Electrical System

Passenger Capacity Alternatives

Passenger Seat Layouts

Vehicle Type

Vehicle Category & Class

RHD M2 Category & Class A

Powertrain System

Drive Type
Battery Electric Vehicle (BEV)

Engine Type
Electric Traction Motor

Maximum Power (kW & hp)

135 & 184

Maximum Torque (Nm)
290

Transmission
Single Speed Automatic Transmission

Performance & Electrical System

Top Speed (km/h)
100

Turning Radius (mm)
6993

Maximum Gradeability (%)
25

Charging (Type - Power - Time)

AC Type 2 - 22 kW - 4h ²
DC Combo 2 - 80 kW - 65 min ²

Range (km) ¹
210

High Voltage Battery (Type - Capacity)
Li-ion - up to 88 kWh

AC Type 3
22kW -4h²

DC Combo 2
80kW - 65min²

1- Based on NEDC testing standards with a base-level equipped vehicle.Range may differ depending on various factors, in particular:individual driving style, route characteristics, outside temperature, heating / air conditionaing, seated and standing passenger weight.

2- Charging up to 80% in ideal conditions

Body

Body Type
Monocoque Space Frame - Original Low Floor (270mm Step Height)

Corrosion Resistance
Cataphoresis Coating & Under Coating

Suspension

Suspension System
4WIS-Four Wheel Independent Suspension System

Front Axle
Independent, MacPherson, Coil Springs & Telescopic Shock Absorber

Rear Axle
Trailing Arm , Helical Spring + Anti Roll Bar

Brakes

Front & Rear Brakes
Hydraulic & Disc

Dimensions

Overall Length (mm)
5845

Overall Width (mm)
2055 (without mirrors)

Overall Height (mm)
2800 (with AC)

Interior Height (mm)
3345 (maximum)

Front Overhang (mm)
1200

Rear Overhang (mm)
950

Wheelbase (mm)
3750

Gross Vehicle Weight (kg)
5000/5200

Tires

Tire Sizes
225/75 R 16C

Rim Sizes
6J x 16

Passenger Capacity Alternatives

Class A
Up to 22 Passengers (88 kWh)

Passenger Seat Layouts

	Battery Capacity	Seated	Foldable	Wheelchair	Max. Standing*	Max. Total Passenger*
M2 Class A	88 kWh	9	-	-	10	19
		9	2	-	8	19
		9	-	1	6	16
		10	-	-	9	19
		10	2	-	7	19
		10	-	1	5	16
M3 Class A		9	-	-	13	22
		9	2	-	11	22
		9	-	1	9	19
		10	-	-	12	22
		10	2	-	10	22
		10	-	1	8	19

1
*Values are examples. These values may change as +/- depending on the selected features.

CONTACT ME BROCHURE GET A QUOTE

e-JEST FEATURES

Style

S Standard

O Option

Exterior Design
LED High Beam & Low Beam Lights	S
LED DRL (Day Time Running Lights)	S
LED Fog Lamps	S
LED 3rd Stop Lamp	O
Rear Clearance Lamps	O
16" Alloy Wheels	S
Double Glazed Side Windows & Transom Windows	S
Sliding Passenger Door	S
Manual Access Ramp	S
Electric Access Ramp²	O
Exterior Passenger Door Opening Button (Under Wiper)	O
Body Colored Bumpers	S
Passenger Compartment
Yellow Handrails	S
Stainless Steel Handrails	O
Stop Buttons on Handrails	S
Q-Straint	S

Technology

S Standard

O Option

Driver Compartment
Leather Steering Wheel	O
Digital Cluster	S
Electric Park Brake	S
Multimedia Touchscreen	S
Speed Limiter (On-off available)	S
2 Mode Regeneration Module	S
Acceleration Limiter (On-off available)	S
Rear Parking Sensor	O
Video & Audio Systems
Radio + USB Port + Bluetooth Connections	S
4 Speakers	S
External Speaker	O
Goose Neck Microphone + Amplifier	O
Passenger Compartment
Stop Sign & Digital Clock	S
USB Ports On Handrails	S
Internet Access Infrastructure (Wi-Fi Router)	O
Line Systems
Heightened Roof Destination Info Preparation with Digital Route Indicator³	O
Farebox Preparation	S

Comfort

S Standard

O Option

Heating & Cooling System
Roof Mounted Passenger AC	S
Driver AC	S
High Voltage Heater	S
Mirrors & Windows
Manual Roof Hatch	O
Electric & Heated Side Mirrors	S
Sidewalk Mirror	S
Manual Sliding Driver Window	S
Heated Front Left Window	S
Heated Windscreen	S
Front Manual Sun Visor (Driver Only)	S
Interior Lights
Driver Area Illumination	S
Passenger Area LED Light Path	S
Driver Compartment
Tiltable & Telescopic Hydraulic Steering Wheel	S
Remote Controlled Central Locking System	S
Driver Seat Without Arm Rest	S
Driver Overhead Bin	S
Semi Closed Driver Cabin	S
Passenger Compartment
Shuttle Type Passenger Seats with 3P Seat Belts	S
Shuttle Type Passenger Seats with Foam and Fabric without Seat Belts	O
Billboard	O
LCD Information Screen Preparation	O
Other
12V Battery	S
The Light Above the Passenger Door	S
Cerb Side Lights	S
Ignition Key	S
Front Side and Destination Sign Preparation	S

⁴With standard heating system.

Safety

S Standard

O Option

ESP - Electronic Stability Program	S
Hill Holder	S
ABS - Anti-lock Braking System	S
EBD - Electronic Brake Force Distribution	S
HBA - Hydraulic Brake Assistant	S
VDC - Vehicle Dynamics Control	S
TCS - Traction Control System	S
DTC - Drag Torque Control	S
TPMS - Tire Pressure Monitoring System	S
Battery Room Fire Detection System	S
Electric Motor Fire Detection System	S
Fire Supression System (For Pre-Heater)¹	O
Brake Pad Wear Sensor	S
Reverse Gear Buzzer	S

¹If pre-heater option is selected, this option must be selected.

CONTACT ME BROCHURE GET A QUOTE

e-JEST - PASSENGER SEATS

SPACIOUS INTERIOR
UTMOST CAPACITY UTILIZATION

e-JEST offers spacious travel possibilities with its roomy interior design, panoramic windows, and ample space between seats so the passengers just need to sit back and relax while viewing the cityscape.
